EUROMOTORS DOUBLE-SHAFT MOTOR 104B-50110/1Q EX 104B-50100/1Q FAN COIL FAN CONVECTOR

EUROMOTORS DOUBLE SHAFT MOTOR 104B-50110/1Q EX 104B-50100/1Q FAN COIL VENTILCONVECTOR

Euromotors double shaft electric motor model 104B-50110/1Q, updated version and replacement of model 104B-50100/1Q, designed for applications on fan coils and ventilconvectors.

The motor guarantees high reliability, stable operation and compatibility with numerous ventilconvector models used in civil and professional environments.

Main technical features:
Brand: Euromotors
Model: 104B-50110/1Q
Replaces: EX 104B-50100/1Q
Type: double shaft motor
Application: fan coil / ventilconvector
Power supply: 230V – 50Hz
Number of speeds: 4
Rotation speed: 1100 RPM
Absorbed power (Wr): 113 W
Maximum absorption (Wa): 300 W
Absorbed current: 1.40 A
Rotation: clockwise (cable outlet side)
Shaft diameter: Ø 12.7 mm
Shaft length: 100 mm per side
Motor body dimensions: 103 × 103 mm

Application and compatibility:
Suitable for replacement of double shaft motors on compatible ventilconvectors and fan coils.
It is recommended to check dimensions, electrical characteristics and rotation direction before purchase.

Note:
Installation recommended to qualified personnel.
Product intended for professional use and maintenance.
