CIMM RP238 FLAT EXPANSION VESSEL 10 L Ø 3/8 FOR HEATING AND REFRIGERATION

CIMM 9310 RP238 is a 10 litre flat circular expansion vessel for closed heating and refrigeration systems, designed to compensate fluid volume variations and maintain stable system pressure.

MAIN FEATURES
flat circular expansion vessel for closed systems
fixed rubber diaphragm membrane
external epoxy powder coating for high corrosion protection
quality certified according to international standards
strict quality controls throughout all production phases

TECHNICAL DATA
product code 9310
model RP238 / 10
capacity 10 litres
dimensions 238 x 516 mm
height 100 mm
water connection M 3/8" Gas
standard pre-charge pressure 1.5 bar
maximum working pressure 3.0 bar
operating temperature from -10°C to +90°C
external finish red
manufactured in compliance with PED 2014/68/EU and DIN EN 13831

APPLICATIONS
suitable for closed circuit heating systems
suitable for refrigeration systems
ideal where a flat, low-profile vessel is required while ensuring long-term pressure stability and safety
