DEPALA M7B3 M SERIES 3-WIRE SERVOMOTOR 230 V WITH AUX CONTACT FOR 2- AND 3-WAY DIVERTER VALVES

DEPALA M7B3 is a 3-wire M series servomotor with 230 V power supply, designed for operating Depala 2- and 3-way diverter valves in thermal systems.

MAIN FEATURES
M series 3-wire servomotor
230 V AC power supply
equipped with AUX contact
90° rotation
suitable for controlling Depala diverter valves
compact design for direct installation on the valve

TECHNICAL DATA
model: M7B3
type: 3-wire electric servomotor
supply voltage: 230 V AC
rotation angle: 90°
AUX auxiliary contact present
compatible with Depala 2- and 3-way valves

OPERATION AND CONTROL
the M series 3-wire servomotor uses separate commands for activating the opening and closing positions
according to the Depala wiring diagram, one thermostat can control one servomotor only
this configuration is intended for installations with dedicated control of a single actuator

APPLICATIONS
ideal for heating systems, boiler-solar integration, DHW storage tanks and thermal systems where dedicated control of a single diverter valve is required
